Eff(%)	Pmpp(W)	Umpp(V)	Impp(A)	Uoc(V)	Isc(A)	FF(%)
25.0	8.25	0.634	13.027	0.720	13.719	83.56
24.9	8.22	0.632	13.016	0.719	13.699	83.46
24.8	8.19	0.630	13.005	0.718	13.680	83.36
24.7	8.16	0.628	12.993	0.717	13.660	83.26
24.6	8.12	0.626	12.982	0.716	13.640	83.16
24.5	8.09	0.624	12.971	0.715	13.620	83.06
24.4	8.06	0.622	12.960	0.714	13.600	82.96
24.3	8.02	0.620	12.948	0.713	13.579	82.86
24.2	7.99	0.618	12.937	0.712	13.559	82.76
24.1	7.96	0.616	12.925	0.711	13.538	82.66
24.0	7.92	0.614	12.913	0.710	13.517	82.56

Condiciones de ensayo estándar: 1000 W/ m², AM 1,5, 25 ℃. Las especificaciones y los datos son solo de referencia.

Dimensión	182mm×182mm±0.25mm，Φ247±0.25mm
Grosor Celular	140μm±14μm
Parte Frontal	Barras conductoras de 0,03±0,015 mm de ancho, 132 dedos, SiOxNy
Parte Posterior	Barras conductoras de 0,03±0,015 mm de ancho, 134 dedos, SiOxNy

Tipo N

Tipo P
